AeroTech F30-4FJ 24mm x 95mm Single Use 1-Motor Pack - 63004

These high performance, composite propellant model rocket motors use the same family of solid propellant as NASAs Space Shuttle Boosters, military missiles, sounding rockets, and NASAs future SLS moon rocket. They utilize a patent pending high-strength polymer case and bulkhead, polymer nozzle and RCSs exclusive Black Max aerospace grade composite propellant formulation, which produces a visible black exhaust plume and a denser dark tracking smoke. Black Max motors provide a higher level of thrust than White Lightning motors of the same total impulse and are perfect for high lift-off acceleration.

This AeroTech motor pack comes with 1 rocket motor and 1 FirstFire Jr. Initiator.

Certified by the Tripoli Rocketry Association (TRA), the National Association of Rocketry (NAR) and the Canadian Association of Rocketry (CAR).

• Specifications

  Motor Diameter 0.938 inches (24mm)

  Casing Length 3.75 inches (95mm)

  Total Impulse 47 N-sec

  Average Thrust 30.4 newtons

  Peak Thrust 40.6 N-sec

  Thrust Duration 1.5 seconds

  Delay Time 4 seconds

  Propellant Weight 31 grams

  Motor Weight 70.3 grams

  Maximum Liftoff Weight Due to the variables involved, AeroTechQuest currently does not list or post recommended maximum lift-off weights for their mid-power and high-power rocket motors. Instead, we recommend utilizing either the RockSim software available at www.apogeerockets.com or OpenRocket Simulator available at www.openrocket.info.
